Manufacturing Company in Brass Industry Since 2000
We are India's leading manufacturer, supplier, and exporter of PG Threaded Single Compression IP68 Cable Glands.
| Technical Details | |
| IP 68 PG THREADED SINGLE COMPRESSION CABLE GLAND | |
| Gland Size | PG 7 to PG 48 |
| IP68 Gland Material | Brass (CuZn39Pb3), Stainless Steel 316L |
| Thread | PG |
| IP Rating | IP68 |
| Operating Temperature | Standard Seals -20°C to +90°C. |
| Cable Types | Unarmoured |
| Finish | Nickel Plated |
| Accessories | Matching Accessories available like PVS Shrouds, Lock Nuts & “O” Ring as per requirement |
| GLAND SELECTION CHART | |||||||
| CODE | GLAND SIZE | THREAD SIZE ‘C’ |
THREAD LENGTH”D” |
ACROSS FLAT(A/F) | CABLE DIAMETER “A” | ||
| PG | PG | MIN | MAX | ||||
| SHORT | LONG | ||||||
| Triera-PG7-6.5 | PG 7 | PG 7 | 6 | 10 | 14 | 3 | 6.5 |
| Triera-PG9-8 | PG 9 | PG 9 | 6 | 10 | 17 | 4 | 8 |
| Triera-PG11-10 | PG 11 | PG 11 | 6 | 10 | 20 | 6 | 10 |
| Triera-PG13-12 | PG 13 | PG 13 | 6.5 | 10 | 22 | 8 | 12 |
| Triera-PG16-14 | PG 16 | PG 16 | 6.5 | 10 | 24 | 10 | 14 |
| Triera-PG21-18 | PG 21 | PG 21 | 7 | 12 | 30 | 13 | 18 |
| Triera-PG29-20 | PG 29 | PG 29 | 8 | 12 | 40 | 13 | 20 |
| Triera-PG29-25 | PG 29 | PG 29 | 8 | 12 | 40 | 18 | 25 |
| Triera-PG36-32 | PG 36 | PG 36 | 8 | 12 | 50 | 22 | 32 |
| Triera-PG42-35 | PG 42 | PG 42 | 9 | 15 | 57 | 27 | 35 |
| Triera-PG42-38 | PG 42 | PG 42 | 9 | 15 | 57 | 32 | 38 |
| Triera-PG48-35 | PG 48 | PG 48 | 10 | 15 | 68 | 29 | 35 |
| Triera-PG48-44 | PG 48 | PG 48 | 10 | 15 | 68 | 37 | 44 |
