We are India's leading manufacturer, supplier, and exporter of Single Compression CW Cable Glands.
| Technical Details | |
| CW 3PT CABLE GLAND | |
| Cable Types | Single Wire Armour (SWA) Aluminium Wire Armour (AWA) |
| Application | CW glands are suitable for indoor and outdoor use with all types of steel wire armoured cables outer seal grips sheath to achieve weatherproof seal |
| IP Rating | IP54 |
| Option Thread | Metric & NPT |
| Gland Material | Brass (CuZn39Pb3) |
| Rubber Seals | Nitrile (NBR) |
| Operating Temperature | (Nitrile): -20°C to +80°C |
| Finish | Natural Brass or Nickel Plated or Electroless Nickel Plated |
| Accessories | PVC/LSF Shroud, Lock Nut, Earth Tag, Serrated Washer, Adaptor / Reducer |
| GLAND SELECTION CHART | ||||||
| CODE | GLAND SIZE | THREAD SIZENPT ‘C’ | THREAD SIZEMETRIC ‘C’ | THREADLENGTH ‘D’ | CABLE RANGE ‘’ | |
| MIN (A) | MAX(B) | |||||
| Triera-CW320S | 20S | 1/2” | M20 | 10 | 11.5 | 15.5 |
| Triera-CW320L | 20L | 1/2” | M20 | 10 | 14 | 20.5 |
| Triera-CW325S | 25S | 3/4” | M25 | 10 | 18 | 24 |
| Triera-CW325L | 25L | 3/4” | M25 | 10 | 20 | 27.2 |
| Triera-CW332S | 32S | 1” | M32 | 15 | 26.3 | 33.5 |
| Triera-CW332L | 32L | 1” | M32 | 15 | 26.3 | 33.5 |
| Triera-CW340S | 40S | 1.1/4” | M40 | 15 | 31.5 | 39.5 |
| Triera-CW340L | 40L | 1.1/4” | M40 | 15 | 32 | 40 |
| Triera-CW350S | 50S | 1.1/2” | M50 | 15 | 38.2 | 46.3 |
| Triera-CW350L | 50L | 1.1/2” | M50 | 15 | 44 | 52.6 |
| Triera-CW363S | 63S | 2” | M63 | 15 | 50.1 | 59 |
| Triera-CW363L | 63L | 2” | M63 | 15 | 56 | 65.3 |
| Triera-CW375S | 75S | 21.2” | M75 | 15 | 62 | 71.6 |
| Triera-CW375L | 75L | 21.2” | M75 | 15 | 68 | 78 |
| Triera-CW390S | 90S | 3” | M90 | 20 | 80.5 | 91 |
| Triera-CW390L | 90L | 3” | M90 | 20 | 80.5 | 91 |
