As India’s top manufacturer, supplier, and exporter of A1 and A2 Type Cable Glands, we deliver unmatched quality and reliability. Known as "stuffing" glands, these components play a vital role in cable management. The A1 gland firmly grips the cable, whereas the A2 gland provides both secure retention and a robust seal, ensuring optimal performance across diverse applications.
| Technical Details | |
| A1/A2 TYPE SINGLE COMPRESSION CABLE GLANDTriera | |
| Cable Types | Unarmoured |
| Application | For indoor and outdoor use with all types of unarmoured cable where it is essential to provide IP66 or IP68 protection on the outer sheath of cable for circular, unarmoured plastic or rubber sheathed cables. |
| Gland Material | Brass (CuZn39Pb3), Stainless Steel (304 or 316L), Aluminium (6082) |
| Option Thread | Metric, NPT, BSP & PG |
| IP Rating | IP66 & IP68 |
| Seal Type | Displacement type |
| Operating Temperature | Standard seals (Nitrile): -20°C to +80°C. on request (silicone) : -60°C to +180°C |
| Finish | Natural Brass or Nickel Plated or Electroless Nickel Plated |
| Accessories | PVC/LSF Shroud, Lock Nut, Earth Tag, Serrated Washer, Adaptor / Reducer. |
| GLAND SELECTION CHART | ||||||||
| CODE | GLAND SIZE | THREAD SIZE ‘C’ | THREAD LENGTH (D) | ACROSS FLAT (A/F) | ACROSS CORNER (A/C) | CABLE DIAMETER “A” | ||
| METRIC (ISO) | NPT | MIN | MAX | |||||
| TRIERA-A1A2-20S16 | 20S16 | M20 | 3/8″ | 10 | 24.5 | 27 | 3.2 | 8.7 |
| TRIERA-A1A2-20S | 20S | M20 | 1/2” | 10 | 24.5 | 27 | 6.2 | 11.7 |
| TRIERA-A1A2-20L | 20L | M20 | 1/2” | 10 | 27 | 30 | 6.5 | 14 |
| TRIERA-A1A2-25 | 25 | M25 | 3/4” | 10 | 36 | 40 | 11.1 | 20 |
| TRIERA-A1A2-32 | 32 | M32 | 1″ | 10 | 41 | 45 | 17 | 26.3 |
| TRIERA-A1A2-40 | 40 | M40 | 1.1/4” | 15 | 50 | 55 | 23.5 | 32.2 |
| TRIERA-A1A2-50S | 50S | M50 | 1.1/2′ | 15 | 55 | 60 | 31 | 38.2 |
| TRIERA-A1A2-50L | 50L | M50 | 2” | 15 | 60 | 66 | 35.6 | 44 |
| TRIERA-A1A2-63S | 63S | M63 | 2” | 15 | 70 | 77 | 41.5 | 49.9 |
| TRIERA-A1A2-63L | 63L | M63 | 2.1/2” | 15 | 75 | 82 | 47.3 | 55.9 |
| TRIERA-A1A2-75S | 75S | M75 | 2.1/2” | 15 | 84 | 92 | 54 | 61.9 |
| TRIERA-A1A2-75L | 75L | M75 | – | 15 | 84 | 92 | 61.2 | 67.9 |
| TRIERA-A1A2-90 | 90 | M90 | 3” | 20 | 108 | 118 | 66.7 | 79.9 |
| TRIERA-A1A2100 | 100 | M100 | 3.1/2″ | 20 | 115 | 125 | 76 | 91 |
